| ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ | |
| Процессор | Intel® Socket 1155 for 3rd/2nd Generation Core™ i7/Core™ i5/Core™ i3/Pentium®/Celeron® Processors Supports Intel® 22 nm CPU Supports Intel® 32 nm CPU Supports Intel® Turbo Boost Technology 2.0 * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. * Refer to www.asus.com for CPU support list |
| Чипсет | Intel® H77 |
| Оперативная память | 4 x DIMM, Max. 32GB, DDR3 2200(O.C.)/2133(O.C.)/2000(O.C.)/1866(O.C.)/1800(O.C.)/1600/1333 MHz Non-ECC, Un-buffered Memory Dual Channel Memory Architecture Supports Intel® Extreme Memory Profile (XMP) * 1600MHz and higher frequency is supported by Intel® 3rd generation processors. * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists). * Due to OS limitation, when installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Install a 64-bit Windows® OS when you want to install 4GB or more memory on the motherboard. * Due to the CPU behavior, DDR3 2133/1866MHz memory module will run at DDR3 2000/1800MHz frequency as default. |
| Графика | Integrated Graphics Processor Multi-VGA output support : HDMI/DVI/RGB/DisplayPort ports - Supports HDMI with max. resolution 1920 x 1200 @ 60 Hz - Supports DVI with max. resolution 1920 x 1200 @ 60 Hz - Supports RGB with max. resolution 2048 x 1536 @ 75 Hz - Supports DisplayPort with max. resolution 2560 x 1600 @ 60 Hz Maximum shared memory of 1696 MB Supports Intel® HD Graphics |
| Поддержка технологий Multi-GPU | Supports AMD Quad-GPU CrossFireX™ Technology Supports LucidLogix® Virtu™ MVP Technology *1 |
| Слоты расширения | 1 x PCIe 3.0/2.0 x16 (blue) 1 x PCIe 2.0 x16 (x4 mode, black) *2 2 x PCIe 2.0 x1 3 x PCI |
| Хранилище данных | Intel® H77 chipset: 2 x SATA 6Gb/s port(s), gray 4 x SATA 3Gb/s port(s), blue Support Raid 0, 1, 5, 10 Supports Intel® Smart Response Technology, Intel® Rapid Start Technology, Intel® Smart Connect Technology |
| Локальная сеть | Qualcomm Atheros, 1 x Gigabit LAN Controller(s) |
| Звук | VIA VT1708S 8-Channel High Definition Audio CODEC - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking Audio Feature: - Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound - Blu-ray audio layer Content Protection - Optical S/PDIF out port(s) at back panel |
| Порты USB | Intel® H77 chipset: *4 4 x USB 3.0 port(s) (2 at back panel, blue, 2 at mid-board) Intel® H77 chipset: 10 x USB 2.0 port(s) (4 at back panel, black, 6 at mid-board) |
| Эксклюзивные функции ROG | Overclocking Protection: - ASUS C.P.R.(CPU Parameter Recall) |
| Особенности | ASUS EPU: - EPU ASUS Digital Power Design: - Industry leading 6 + 1 + 2 Phase Power Design - ASUS DIGI+ VRM Utility ASUS Protect 3 Technology: - Anti-Surge Protection - Low EMI Solution - ESD TurboV GPU Boost ASUS Exclusive Features: - MemOK! - AI Suite II - USB 3.0 Boost ASUS Quiet Thermal Solution: - Stylish Fanless Design Heat-sink solution & MOS Heatsink - ASUS Fan Xpert - ASUS Q-Fan ASUS EZ DIY: - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 - ASUS MyLogo 2 ASUS Q-Design: - ASUS Q-Slot 100% All High-quality Conductive Polymer Capacitors |
| Разъемы на задней панели | 1 x PS/2 keyboard/mouse combo port(s) 1 x DVI 1 x D-Sub 1 x DisplayPort 1 x HDMI 1 x LAN (RJ45) port(s) 2 x USB 3.0 4 x USB 2.0 1 x Optical S/PDIF out 6 x Audio jack(s) |
| Разъeмы на плате | 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) 3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s) 1 x COM port(s) connector(s) 2 x SATA 6Gb/s connector(s) 4 x SATA 3Gb/s connector(s) 1 x CPU Fan connector(s) 2 x Chassis Fan connector(s) 1 x Power Fan connector(s) 1 x S/PDIF out header(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x System panel(s) 1 x MemOK! button(s) 1 x GPU Boost switch(es) 1 x Clear CMOS jumper(s) |
| Аксессуары | User's manual I/O Shield 2 x SATA 6Gb/s cable(s) |
| BIOS | 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.6, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, F12 PrintScreen Function |
| Администрированиe | WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE |
| Диск с драйверами | Drivers ASUS Utilities ASUS Update Anti-virus software (OEM version) |
| Форм-фактор | ATX Form Factor 12 inch x 7.8 inch ( 30.5 cm x 19.81 cm ) |
| Примечание | *1: PCIe 3.0 speed is supported by Intel® 3rd generation Core™ processors. *2: Supports on Intel® Core™ processors under Windows® 7 operating system. *3: Use a chassis with HD audio module in the front panel to support an 8-channel audio output. |
