CNET CQR-980 Wireless N Pico Broadband Router

 CQR-980 is the first in a new series of mini sized broadband routers from CNet. With a small footprint, this tiny router offers wired and wireless-N access on LAN, and Cable/DSL or Wi-Fi network connectivity on the WAN side.
With automatic WAN type detection, users can easily connect and share their Internet access in no time. To provide wireless security, the router not only supports WEP/WPA/WPA2 and WPS standards but can also partition WLAN network for more security.
Anbarda: Tükənmişdir
Təyin edilməyib
Mal haqqında

Модель Wireless-N PicoBroadband Router
Standards IEEE 802.3u
IEEE 802.3x
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
Channels 1-11 (FCC)
1-13 (ETSI)
Interface •Four 10/100M 802.3u (RJ-45) interface with auto MDI/MDI-X
•One RJ11 port for ADSL connection
•One reset button for restoration of factory default setting
•One Power ON/OFF switch
Ethernet Port WAN: 1port 10/100Mbps RJ-45 with autoMDI/MDIX
LAN: 1 port 10/100Mbps RJ-45 with AutoMDI/MDIX
Data Rate 11b: 11/5.5/2/1 Mbps
11g: 54/48/36/24/18/12/9/6 Mbps
11n (20MHz): up to 72Mbps
11n (40MHz): up to 150Mbps
Modulation 11b: DSSS with BPSK, QPSK, CCK
11g: OFDM with BPSK, QPSK, 16QAM, 64QAM
11n: OFDM with BPSK, QPSK, 16QAM, 64QAM
Wireless Security WEP 64/128
WPA
WPA2 Mix
802.1x
Transmit Power IEEE 802.11b: 19dBm +/- 2dBm @ normal temp. range
IEEE 802.11g: 16dBm +/- 2dBm @ normal temp. range
IEEE 802.11n(20/40MHz): 14 +/-2.0dBm @ normal temp. range
Receive Sensitivity 11b: -83 dBm @ 8% PER
11g: -70 dBm @10% PER
11n (20MHz): -64dBm @10% PER
11n (40MHz): -61dBm @10% PER
LED 1 x Power/Status: Green
1 x LAN: Green
1 x WAN: Green
1 x Wireless / WPS: Green/Orange
Dimension 3.52 (L) x 2.32 (W) x 1.06 (H) inches ( 88 x 58 x 26.5 mm)

  Рекомендуем посмотреть: CNET Wireless N Pico 3.5G Broadband Router CQR-981
